When you take a snapshot of data on the Histogram display, the flyover text on the Undo button now correctly states, “Undo Create Histogram Snapshot”. We have now prevented the user from doing funky things that don’t make sense when they start recording on the Welcome Screen. Turns out you could change a measurement name to no name (empty string) and you could have more than one measurement set to no name. We removed an unintentional back door to creating a second plot area in the Scope display. The multi-coordinates graph tool is no longer partially obscured when you pin the graph toolbar. Finally fixed this one.įixed some issues that occurred when changing the camera’s Frame Size property to a high resolution.įixed a nasty little bug where sometimes data in a selection rectangle on the graph was not really selected. The graph legend was being hidden by the second Y axis on the right side of the graph. The Frame Rate and Frame Size properties now actually match the camera’s capabilities. The graph legend now behaves correctly when you undo changing measurements on the Y axis. It now returns the correct results.įixed an issue where a calculation using a Model Range could return the same result for every value in the range.įixed a problem with the graph rearrange button not behaving correctly during a save and open. We squashed that bug.Ī calculation that was operating on two video analysis measurements would return incorrect data after being refreshed.
#Change resolution on pasco capstone software code#
When you cancelled the creation of a Code Output in the Code window, it would leave an unnamed object.
Sometimes the Area tool was returning 0.00 when using a selection on a portion of the data in the graph. They no longer do that.įixed an issue where when you pasted data values into a UED in a table (from Excel or something like it), and you have a calculation that operates on the UED, any graph using that calculation was not being updated. The data point context tools were running off the edge of the screen when you clicked on a point near the edge of the graph. The Position measurement is now visible by default on the PS-2120(A) Rotary Motion Sensor. The default data export format is now CSV (Comma Separated Values). This reduces clutter in the Hardware tab of the Code window.ĭata files exported as Tab delimited now have an extension of “.tsv”. We now hide Hardware specific blocks until the Hardware to which they apply is connected. Data appearance is now applied only to the selected data or it can now be setup before a run is taken.Īdded a waveform block in Code to set the waveform of a signal generator.Īdded the ability to Export and Import Code for sharing and code reuse.Īdded notes blocks in Code to annotate your code.Īdded a “clear all” option to the block in Code to just turn off all the lights in the //code.Node array. Improved the usage of the Data Appearance in the Graph.
The Capstone Help has been updated and is now available online through the Help menu in Capstone and through the browser at URL: It also includes several feature improvements and a good number of bug fixes.Īdded support for the Water Quality Attachment to the Wireless Colorimeter.Īdded support for the Wireless EKG Sensor.Īdded support for the Wireless Soil Moisture sensor.
